ABG International Vectra ECTR-4 (410 mm)
with Inline Unwinder/Slitter (2009)

Your Benefits at a Glance:

• Maximum Automation: Significantly reduces manual intervention through an automated winding process.

• All-in-One System: Integrated unwinding, slitting, and turret rewinding for a continuous production flow.

• Superior Roll Quality: Precise winding results maintained at consistently high speeds.

• Space-Saving Design: A compact unit that makes efficient use of your production floor space.

• Proven Reliability: Robust ABG engineering ensures high operational uptime.

Key Specifications:

• Model: ABG Vectra ECTR-410

• Function: Automatic Turret Rewinder incl. Inline Slitting

• Year of Manufacture: 2009

Used Automatic Butt Splicer for Efficient Web Processing

Available for sale is a used MBS Automatic Butt Splicer, manufactured in 2020. This machine is designed to provide reliable and precise automatic butt splicing during roll changes, helping to minimize downtime and maintain continuous production.

With its robust construction and proven technology, the MBS Automatic Butt Splicer is an excellent solution for companies seeking a cost-effective alternative to new equipment while maintaining high production efficiency and splice quality.

Key Features

• Year of manufacture: 2020
• Automatic butt splicing operation
• High splice accuracy and process reliability
• Reduced production downtime during roll changes
• Robust industrial design
• Suitable for integration into existing production lines
• Cost-effective alternative to a new machine

Technical Information

• Model: MBS Automatic Butt Splicer
• Year: 2020
• Condition: Used
• Availability: Upon request

Benefits

• Increased production efficiency
• Reliable web splicing performance
• Lower investment cost compared to new equipment
• Short lead time and immediate availability
• Proven industrial technology

Condition

The machine is offered in used condition and is available for inspection upon request. Additional technical details, photographs, and documentation can be provided.

Availability

Available immediately, subject to prior sale.

ABG International Vectra ECTR 410 automatic turret rewinder (2009 model)

• Maximum web width: 410 mm
• Maximum rewind diameter: Up to 350 mm
• Mechanical speed: Up to 150 m/min (depending on mandrel size)
• Spindle system: 4-spindle turret rewinder
• Standard mandrel size: 76 mm (3 inches) air shafts
• Cycle time: Full cycle in approximately 8 to 10 seconds
• Tension control: Precise, constant automatic web tension
• Core functions: Automatic roll ejection, counter (labels or meters)

This machine is available immediately – pleaese contact us for more information

Printum Stäudle Digital 350 label converting line from 2019

Manufacturer: Printum
Model: Staudle Digital 350
Year of manufacture: 2019

Equipment:

• Unwinder
• Web Guide
• Corona treatment
• Nip rollers
• Gallus Printing unit
• GEW UV Dryer
• Buffer
• 2. Web guide
• BST Eltromat Inspection Camera
• Control Unit with touch screen
• Rotary die cutter with GapMaster
• 2. Buffer
• Slitting unit
• Double Rewinder

Processing width: 350 mm
Minimum web width: 330 mm
Maximum web width: 100 mm
Maximum web speed: 100 m/min

Machine is available immediately.

Technical Specification: SMAG Galaxie Digital (2016 Model)

Type: Modular converting and finishing system for self-adhesive labels.

1. Unwinding Unit

• Servo-driven unwinder supporting roll diameters up to 650–700 mm.
• Standard web tension control system for consistent material flow.
• Integrated splice table with mechanical or pneumatic web clamping.

2. Web Guide System (E+L)

• System: Erhardt + Leimer (El Guider).
• Function: Proven sensor-controlled web guiding to ensure correct material positioning prior to the processing modules.

3. Corona Treatment

• Integrated corona station for surface energy treatment.
• Purpose: Improves ink and varnish anchorage, particularly useful for synthetic or non-absorbent digital print substrates.

4. Flexographic Coating Unit

• Configuration: Servo-driven flexo unit designed for full-surface or spot varnishing.
• Curing: Standard UV drying system (mercury vapor lamps).
• Technology: Precision anilox roller system for consistent varnish application.

5. Semi-Rotary Die-Cutting Unit

• Technology: Servo-driven die-cutting module.
• Mode: Semi-rotary operation, allowing for variable repeat lengths without the need to change magnetic cylinders, significantly reducing setup times for short-run production.
• Registration: Optical mark registration system for accurate die-cutting in relation to the digital print image.

6. Slitting Unit

• System: Standard shear knife or razor blade slitting station.
• Function: Precise longitudinal cutting of the web.
• Waste Management: Integrated trim extraction/vacuum system for edge waste.

7. Rewinding Unit

• Rewinder with adjustable tension control to ensure high-quality, stable roll formation.
• Standard air-expanding shaft for 76 mm (3 inch) cores.

Machine Highlights (2016 Edition)

• Control System: Established HMI interface for machine monitoring and parameter setting.
• Efficiency: Designed for the challenges of 2016-era digital print finishing, focusing on high reliability and reduced waste during setup.
• Application: Optimized for finishing mid-to-short run digital labels, providing reliable varnish and die-cutting quality in a single, streamlined process.

Iwasaki TR2 Label Press (2004)

High-Quality Intermittent Offset Label Printing Solution

Available immediately, this Iwasaki TR2 from 2004 is a versatile and highly productive label printing press designed for premium label production. The machine combines intermittent offset printing, flexographic varnishing, hot foil stamping, and die-cutting capabilities in one efficient production line.

Key Features

• 5 intermittent offset printing units
• 1 intermittent flexographic varnishing unit
• 1 intermittent rotary die-cutting unit
• 2 hot foil stamping units
• 1 flatbed die-cutting unit
• Waste rewinder

Technical Specifications

Applications

• Self-adhesive labels
• Premium product labels
• Cosmetic labels
• Pharmaceutical labels
• Wine and beverage labels
• Security and decorative labels

For further information, technical details, pricing, or inspection arrangements, please contact us.

ABG Vectra 410 mm 16 inches – Automatic Turret rewinder – Nice machine for long runs

ABG Vectra STR 410 Autmatic Turret Rewinder

Machine Details:

• Manufacturer: ABG International
• Product Line: Vectra
• Model: ABG Vectra STR 410 (Turret Rewinder)
• Web Width: 410 mm (16″)
• Date of Manufacture: August 2008

Characteristics oft he turret rewinder

• 410 mm web width
• Four-spindle turret rewinding system
• Automatic roll change capability
• Hot-melt tail sealing system
• Swing-arm mounted operator control panel
• Vectra-series machine frame and guarding

• 410 mm web width
• Automatic turret rewinding system
• Hot-melt tail sealing
• Manufactured: August 2008
• Supplied by ABG International, United Kingdom
• The electrical cabinet documentation
• The machine manual
